Warn 3000ACI - Components and Dimensions; Components Overview; Dimensional Data

PAGE 6 85366 Rev. A0
Parts List
The WARN
®
3000ACI Utility Winch consists of the following main components.
1. Powerfull .75 hp TEFC Induction Motor
2. Large Drum with 100‖ of 5/16 Cable
3. 3-Stage Planetary Geartrain with clutch
4. Station type control switch
5. Hardware Pack With Clasp Hook
Dimensional Data for the WARN 3000ACI
1
2
3
4
5
