PAGE 7 85366 Rev. A0
Specification Data for the WARN 3000ACI
Features
Pulling Capacity
3000lbs. (1361 kg)
Brake
Dynamic and Mechanical braking
Switch Type
GE Drum Switch CR102A1 Station Type
Warranty
1 year limited
Motor
TEFC Induction AC Motor
Wire Rope
5/16" X 100' (18.3 m)
HP
.75 HP 56C
Drum Diameter
2.5" (6.35 cm)
Power
120V 60 Hz or 230V 50Hz Single Phase AC
Fairlead
None
Gear Train
3-Stage planetary
Hole Pattern
4 holes
Gear Ratio
216:1
Electrical Leads
None
Clutch
Lever actuated sliding ring gear
Weight
76 lbs. (34.5 kg.)
Performance Data for the WARN 3000ACI
PERFORMANCE DATA: 3000ACI
115V 60Hz Single Phase
Load
Current
Speed
Pulling Power by Wire Rope Layer
Lbs.
Kg
Amps
KW
Ft/min
M/min
Layer
lbs.
kg
0
0
9.1
1049
12.2
3.7
1
3000
1361
1000
453.6
11.0
1265
8.8
2.7
2
2700
1225
1500
680.4
12.7
1461
8.8
2.7
3
2460
1116
2000
907.2
14.8
1702
8.6
2.6
4
2250
1021
2500
1134
17.7
2036
8.5
2.6
5
2070
939
3000
1360.8
20.9
2300
8.1
2.5
PERFORMANCE DATA: 3000ACI
230V 50Hz Single Phase
Load
Current
Speed
Pulling Power by Wire Rope Layer
Lbs.
Kg
Amps
KW
Ft/min
M/min
Layer
lbs.
kg
0
0
4.6
1058
12.2
3.7
1
3000
1361
1000
453.6
5.5
1265
8.8
2.7
2
2700
1225
1500
680.4
6.4
1472
8.8
2.7
3
2460
1116
2000
907.2
7.4
1702
8.6
2.6
4
2250
1021
2500
1134
8.9
2047
8.5
2.6
5
2070
939
3000
1360.8
10.5
2415
8.1
2.5
