Warn 87355 - Caution: Moving Parts Entanglement Hazard; Tools Required; Torque Specifications

©2011 Warn Industries, Inc.WARN® and the WARN logo are trademarks of Warn Industries Inc. 2 88126A0
NOTICE
EQUIPMENT DAMAGE
• AlwaysrefertotheInstallationandSpecicationGuide,suppliedinthewinchkit,forallwiringschematicsandspecicdetailsonhowtowirethisWARNproducttoyourvehicle.
• Never overtighten the j-bolt to the bracket. Doing so will pinch the winch cable against the bracket, damaging the cable.
• Always put the end of the actuator cable through the slot in the Termination Bracket. Terminating the cable through any other hole in the bracket will cause the bracket to not
function properly and will drastically reduce the life of the actuator cable.
Read installation and operating instructions thoroughly.
CAUTION
MOVING PARTS ENTANGLEMENT HAZARD
Failure to observe these instructions could lead to minor or moderate injury
• Always take time to fully read and understand the installation and Operations Guide included with this product.
• Never operate this product if you are under 16 years of age.
• Neveroperatethisproductwhenundertheinuenceofdrugs,alcoholormedications.
Read installation and operating instructions thoroughly.
TABLE OF CONTENTS
Tools Required .......................................................................................................page 2
Torque Specications ............................................................................................page 2
Parts List ................................................................................................................page 3
Installation ......................................................................................................... page 4-5
Maintenance/Care ................................................................................................ page 5
TOOLS REQUIRED
- 13mm Wrench
- 13mm Socket
- Socket Wrench
TORQUE SPECIFICATIONS
1/4 (6mm) 8 lb. ft. (10.8 N-m)
5/16 (8mm) 17 lb. ft. (12.5 N-m)
3/8 (10mm) 30 lb. ft. (40.7 N-m)
7/16 (11mm) 50 lb. ft. (67.8 N-m)
1/2 (13mm) 75 lb. ft. (101.7 N-m)
