Warn 87355 - Parts List

©2011 Warn Industries, Inc.WARN® and the WARN logo are trademarks of Warn Industries Inc. 3 88126A0
PARTS LIST
Description Qty Ref.
Plow Mount 1 A1
Bracket RH 1 A2
Bracket LH 1 A3
Large Washers 1 A4
J Bolt Bracket 1 A5
M8 Hex Head Bolts 6 B1
Flat Washers 10 B2
Lock Nuts 4 B3
1/4-20 J-Bolt 2 C1
3/8-16 x 1 Hex Bolt 2 C2
3/8” Flat Washer 2 C3
3/8-16 Lock Nut 2 C4
1/4” Flat Washer 2 C5
1/4-20 Lock Nut 2 C6
C1
C3
C4
A5
C5
C6
C2
A2
A1
B1
A4
B3
B2
A3
