s1fmdl1sm-REV1207 Model S1F Metallic Page 13
ITEM PART NUMBER DESCRIPTION QTY
1 031-140-001 Air Valve Assembly (Cast Iron Centers Only) 1
031-146-000 Air Valve Assembly (Stroke Indicator) 1
031-147-000 Air Valve Assembly(Stroke Indicator) 1
031-183-000 Air Valve Assembly 1
031-183-001 Air Valve Assembly
(W/ Stainless Steel Hardware) 1
031-173-000 Air Valve Assembly
(W/ Aluminum centers only) 1
031-173-001 Air Valve Assembly
(W/ Stainless Steel Hardware only) 1
2 050-028-354 Ball, Check 4
050-028-360 Ball, Check 4
05`0-028-365 Ball, Check 4
050-028-600 Ball, Check 4
3 070-012-170 Bushing 2
4 095-110-000 Pilot Valve Assembly 1
095-110-558 Pilot Valve Assembly 1
(Cast Iron Centers Only)
5 114-025-157 Intermediate 1
114-025-010 Intermediate 1
6 132-019-360 Bumper 2
7 135-036-506 Bushing 2
8 165-120-157 Cap, Air Inlet Assembly 1
165-120-010 Cap, Air Inlet Assembly 1
9 170-044-115 Capscrew, Hex Hd 5/16-18 X 1.00 16
170-044-330 Capscrew, Hex Hd 5/16-18 X 1.00 16
10 170-045-115 Capscrew, Hex Hd 5/16-18 X 1.25 16
170-045-330 Capscrew, Hex Hd 5/16-18 X 1.25 16
11 170-069-115 Capscrew, Hex Hd 5/16-18 X 1.75 4
170-069-330 Capscrew, Hex Hd 5/16-18 X 1.75 4
12 171-053-115 Capscrew, Hex Soc 3/8-16 X 2.50 4
(Stroke Indicator option only)
171-053-330 Capscrew, Hex Soc 3/8-16 X 2.50 4
(Stroke Indicator option only)
170-006-115 Capscrew, Hex HD 3/8-16 X 1.00 4
170-006-330 Capscrew, Hex HD 3/8-16 X 1.00 4
13 196-173-156/157 Chamber, Outer 2
196-173-010 Chamber, Outer 2
196-173-110 Chamber, Outer 2
14 286-008-354 Diaphragm 2
286-008-360 Diaphragm 2
286-008-363 Diaphragm 2
286-008-364 Diaphragm 2
286-008-365 Diaphragm 2
286-112-000 Diaphragm, One-Piece Bonded 2
15 286-015-604 Diaphragm, Overlay 2
16 360-093-360 Gasket, Air Valve 1
17 360-103-360 Gasket, Pilot Valve 1
18 360-104-379 Gasket, Air Inlet Cap 1
19 518-175-156 Manifold, Suction 1
Composite Repair Parts List
518-175-156E Manifold, Suction 1" BSP Tapered 1
518-175-010 Manifold, Suction 1
518-175-010E Manifold, Suction 1" BSP Tapered 1
518-175-110 Manifold, Suction 1
518-175-110E Manifold, Suction 1" BSP Tapered 1
20 518-176-156 Manifold, Discharge 1
518-176-156E Manifold, Discharge 1" BSP Tapered 1
518-176-010 Manifold, Discharge 1
518-176-010E Manifold, Discharge 1" BSP Tapered 1
518-176-110 Manifold, Discharge 1
518-176-110E Manifold, Discharge 1" BSP Tapered 1
21 560-001-360 O-Ring 2
22 560-091-360 Seal (Check Valve) (See item 29) 8
560-091-363 Seal (Check Valve) (See item 29) 8
560-091-364 Seal (Check Valve) (See item 29) 8
560-091-365 Seal (Check Valve) (See item 29) 8
560-091-611 Seal (Check Valve) (See item 29) 8
23 612-022-330 Plate, Inner Diaphragm 2
612-218-330 Plate, Inner Diaphragm 2
(use with One-Piece Bonded)
24 612-108-157 Plate, Outer Diaphragm Assembly 2
612-101-082 Plate, Outer Diaphragm Assembly 2
612-101-110 Plate, Outer Diaphragm Assembly 2
25 620-022-115 Pin, Actuator 2
26 675-042-115 Ring, Retaining 2
27 685-060-120 Rod, Diaphragm 1
28 720-010-375 Seal, U-Cup 2
29 722-098-550 Seat, Check Ball 4
722-098-080 Seat, Check Ball (seals required see item 22) 4
722-098-110 Seat, Check Ball (seals required see item 22) 4
722-098-150 Seat, Check Ball (seals required see item 22) 4
722-098-600 Seat, Check Ball 4
30 900-004-330 Lock Washer, 5/16 16
900-004-115 Lock Washer, 5/16 16
31 901-038-330 Flat Washer, 5/16 4
901-038-115 Flat Washer, 5/16 4
32 530-033-000 Muffler, Metal 1
Parts not shown used with Raised Face Flange Porting Option
170-044-330 Hex Cap Screw 4
326-050-080 Mounting Bracket 2
334-112-110 1" Raised Face, 150# ANSI Flange 2
538-035-110 Pipe Nipple 1" NPT x 1½" 2
545-004-330 Hex Nut 4
900-004-330 Lock Washer 4
901-009-330 Flat Washer 8
ATEX Compliant
ITEM PART NUMBER DESCRIPTION QTY
