s1fmdl1sm-REV1207 Model S1F Metallic Page 2
Check Diaphragm/ Check Non-Wetted Shipping
MODEL Pump Pump Valve Design Wetted Check Valve Valve Material Porting Pump Pump Kit Weight
Brand Size Type Level Material Materials Seat Options Options Style Options Options lbs. (kg)
S1FB1ABWANS000. S 1F B 1 A B W A N S 0 00. 28 (13)
S1FB1AIWANS000. S 1F B 1 A I W A N S 0 00. 28 (13)
S1FB1AGTANS000. S 1F B 1 A G T A N S 0 00. 28 (13)
S1FB1ANWANS000. S 1F B 1 A N W A N S 0 00. 28 (13)
S1FB1A1WANS000. S 1F B 1 A 1 W A N S 0 00. 28 (13)
S1FB1ACTANS000. S 1F B 1 A C T A N S 0 00. 28 (13)
S1FB1IBWANS000. S 1F B 1 I B W A N S 0 00. 46 (21)
S1FB1IIWANS000. S 1F B 1 I I W A N S 0 00. 46 (21)
S1FB1IGTANS000. S 1F B 1 I G T A N S 0 00. 46 (21)
S1FB1INWANS000. S 1F B 1 I N W A N S 0 00. 46 (21)
S1FB1I1WANS000. S 1F B 1 I 1 W A N S 0 00. 46 (21)
S1FB1ICTANS000. S 1F B 1 I C T A N S 0 00. 46 (21)
S1FB1IIWANS000. S 1F B 1 I I W A N S 0 00. 46 (21)
S1FB1SBWANS000. S 1F B 1 S B W A N S 0 00. 43 (20)
S1FB1SGTANS000. S 1F B 1 S G T A N S 0 00. 43 (20)
S1FB1SNWANS000. S 1F B 1 S N W A N S 0 00. 43 (20)
S1FB1S1WANS000. S 1F B 1 S 1 W A N S 0 00. 43 (20)
S1FB1SCTANS000. S 1F B 1 S C T A N S 0 00. 43 (20)
Diaphragm Check Valve
Materials
1= Santoprene/Santoprene
B= Nitrile/Nitrile
C= FKM/PTFE
I = EPDM/Santoprene
G= PTFE-Neoprene/PTFE
N= Neoprene/Neoprene
Z= One-Piece Bonded/PTFE
Check Valve Seat
A= Aluminum
C= Carbon Steel
S= Stainless Steel
T= PTFE
W= UHMW
Non-Wetted Material Options
A= Painted Aluminum
I = Cast Iron
Y= Painted Aluminum with
Stainless Steel Hardware
Z= Cast Iron with
Stainless Steel Hardware
Porting Options
N= NPT Threads
B= BSP (Tapered) Threads
R= Raised Face 150#
Threaded ANSI Flange
Pump Style
S= Standard
Pump Options
0= None
1= Sound Dampening Muffler
2= Mesh Muffler
3= High temperature Air Valve
w/Encapsulated Muffler
4= High temperature Air Valve
w/Sound Dampening Muffler
5= High temperature Air Valve
w/Mesh Muffler
6= Metal Muffler
7= Metal Muffler with Grounding Cable
Kit Options
00.= None
P0.= 0-30VDC Pulse Output Kit
P1.= Intrinsically-Safe 130VDC,110/120VAC,
220/240VAC Pulse Output Kit
P2.= 110/120 or 220/240VAC Pulse Output Kit
E0.= Solenoid Kit with 24VDC Coil
E1.= Solenoid Kit with 24VDC Explosion-Proof Coil
E2.= Solenoid Kit with 24VAC/12VDC Coil
E3.= Solenoid Kit with 24VAC/12VDC Explosion-Proof Coil
E4.= Solenoid Kit with 110VAC Coil
E5.= Solenoid Kit with 110VAC, 60 Hz Explosion-Proof Coil
E6.= Solenoid Kit with 220VAC Coil
E7.= Solenoid Kit with 220VAC, 60 Hz Explosion-Proof Coil
E8.= Solenoid Kit with 110VAC, 50 Hz Explosion-Proof Coil
E9.= Solenoid Kit with 230VAC, 50 Hz Explosion-Proof Coil
SP.= Stroke Indicator Pins
Pump Brand
S= SANDPIPER
®
Pump Size
1F=1"
Check Valve Type
B= Ball
Design Level
1= Design Level
Wetted Material
A= Aluminum
I = Cast Iron
S= Stainless Steel
H= Alloy C
Explanation of Pump Nomenclature, S1F Metallic · Design Level 1· Ball Valve
Note: Pumps are only ATEX compliant
when ordered with
pump options 6 or 7,
and
kit options 00, P1, E1, E3, E5, E7, E8 or E9.
