Wascomat D783 - Siting; Mechanical Installation

Installation manual
25
3.2 Siting
The machine should be positioned so that there is plenty of room for working, both for the user and service personnel.
The figure shows minimum distance to a wall and/or other machines.
Min. 20 mm /
13/16 inch
fig.7187
3.3 Mechanical installation
Level the machine with the feet of the machine. The maximum height adjustment of the feet is 15 mm / 9/16 inch.
fig.W00859A
Remount the panels.
