Installation manual
27
5 Reversing the door
Disconnect the power to the machine.
Demount the hinges and remove the door. Remove the upper hinge first.
fig.7166
Remove the screws on the front panel and carefully loosen the panel. Push the door switch cable down through the
hole in order to access the cable and then disconnect the cable. Remove the panel.
fig.7548
Move the door switch cable to the opposite side.
Note!
The plastic plug MUST be placed in the hole where the door switch cable was before.
fig.7170
