Wascomat D783 - Page 29

Installation manual
29
Move the four metal clips from the opposite side.
fig.7174
Connect the door switch cable and push the cable in over the drum and pull it upwards.
fig.7549
Remount the front panel.
Ensure that the door switch cable does not get damaged when remounting the front panel.
Fasten the hinges and mount the door on the opposite side.
Connect the power to the machine.
Test run the machine.
