43
59
1210
60
1211
If the machine does not extract
A Check the extract relay and relay coil
for proper operation.
If the motor does not operate at wash speed
A Check the wash relay(s).
B Check the normally-closed contact of the
extract relay.
C Check the motor and V-belt.
D Review procedures outlined under section ”If
machine does not start”.
A
A
B
C
Trouble shooting
Fig.
59
Fig.
60
