Wascomat SW-12P - Removing Transportation Bolts

12
Installation manual
5.3 Removing Transportation Bolts
1. Unscrew the 4 bolts with a wrench. Remove the lower 2 bolts first, then the upper two. One of bolts retains the
power cord of the washer to prevent operating without removing bolts.
2. Remove the bolts and the red plastic sleeves to release the power cord. Keep the 4 bolts and sleeves for future
use.
Note!
If transportation bolts and sleeves are not removed, it may cause severe vibration, noise and malfunction,
as well as damage to the machine.
Note!
When the washer is transported the transportation bolts and the sleeves must be reinstalled.
3. Close the 4 holes with the caps supplied.
1
2
4
4
3
3
5
fig.W01597
1 Brace
2 Cap
3 Bolt
4 Sleeve
5
Screws
