Wascomat W655 Classic - Page 111

Service
Manual
5
42
42. Instruction for pulley and replacing bearings
Fig.
4
• Gänga axeländan M12 och 20 mm djupt.
• Thread the shaft end with M12 and 20 mm deep.
5
367
• Montera adapter G 1/2"/M12 i axeländan. Gänga ner den i botten.
• Mount adaptor G 1/2"/M12 in the shaft end. Thread it to the bottom.
Fig.
5
Montering av remskiva/Mounting pulley
4
362
• Drag loss remskivan.
• Pull off the pulley.
