38. Drain valve
Service
Manual
Assembling
1. Connect the pressure hose to the lower part of the valve. Verify that the
hose is not bent or pinched.
2. Fit the rubber bellows onto the sleeve coupling.
3. Hook the valve onto the bolts and turn the valve into position. Secure the
4 retaining bolts of the valve.
4. Secure the hose clamp at the connection of the rubber bellows on the
sleeve coupling.
5. Connect the drain hose to the upper part of the valve.
6. Turn the main power switch to position 1 and verify correct valve
operation and that it does not leak.
7. Reattach the front cover.
