30
30. Motor
4
Service
Manual
Fig.
1
1
Description
Motor
The motor is fitted in a bridge carrier under the
outer drum. It drives the washing drum using a
drive belt.
The motor is controlled by contactors.
The motor winding is protected against
overloads using a thermal overheating protector
that is automatically reset.
The motor is connected directly to the motor
module via a cable with quick connectors.
5467, 5465
Motor
Rotation sensor
B3
2
5975
Programme unit
A1
Rotation
control card
A31
X24
X94 X97
X95
B3
Motor
Contactors
A107
1 or 3-phase
Thermal
protection
X27 X26
