Wascomat W655 Classic - Motor Wiring Diagrams

5
30
30. Motor
Service
Manual
3
5973
5974
Single phase
Three phase
1
K1
2
4
13
4
3
2
K2
K4
4
13
2
Black
Blue
White
21
22
C1-2
K4
White
Black
Blue
21
22
C3-6
C3-6
Aux
Main
Wash speed (18-pole) Extract speed (2-pole)
A Only machines with start switch
Note! Some machines may hav overcurrent protection.
This is not shown here.
A
Principle wiring
4
3
6
5
2
1
4
3
6
5
2
1
K1 K2
Black
Blue
White
Black
Blue
White
4
3
6
5
2
1
K4
Note! Some motors are possible to change from Y to D-connection to accomodate different voltages.
