Wascomat W655 Classic - Page 21

5
2
2. Technical data
Service
Manual
in inch A B C D E F G H I K
W620 26 28 3/4 43 7/8 14 30 1/8 32 1/2 1 3/4 40 9/16 8 7/16 39 3/4
W630 28 3/8 31 1/8 47 1/4 14 3/8 32 1/2 35 13/16 1 3/4 40 7/8 8 7/16 43 1/8
W640 29 1/2 34 5/8 52 3/16 17 1/8 36 40 3/4 1 3/4 49 5 1/8 48 1/4
W655 32 11/16 37 5/8 55 1/2 19 1/2 39 44 1/8 1 3/4 52 3/8 6 5/16 50 13/16
W675 35 13/16 40 15/16 56 7/8 19 11/16 42 5/16 45 1/2 1 3/4 53 3/4 6 5/16 52 3/16
in inch L M N O P R
W620 5 1/8 32 11/16 15 3/16 – 3 15/16 8 1/4
W630 5 1/8 35 13/16 16 9/16 – 3 15/16 9 1/4
W640 8 1/4 40 15/1612 13/16 11 5/8 3 15/16 8 7/8
W655 9 5/8 44 5/16 12 13/16 12 13/16 3 15/16 10 7/16
W675 9 5/8 45 1/2 11 12 13/16 3 15/16 8 1/4
A
D
C
8
10
7
B
E
N
P
R
F
L
G
I
1
2
3
9
4
5
6
5281
5282 5283
K
M
H
5
W620-630
5459
N
G
3
L
O
I
2
P
6
9
K
M
H
R
F
1
4
5
Rear side
Right sideFront Rear side
W640-675
