21. Control unit
14
Service
Manual
5600
11
12
5601, 5602
There are some possibilities to alter the standard
parameters in the wash programs by moving or
adding jumpers on the option card.
•When adding a jumper on N or M gives warm
rinses instead of cold. M shall be used on
W375-W3130N, W620-630 and N on
W3180N-W3330N and W640-675.
3 spare jumpers
Fig.
11
Fig.
12
