EXPLODED PERSPECTIVE VIEW
A
PERSPECTIVE VIEW
B
C
FRONT VIEW
A
Parts List
QTYDESCRIPTIONPART NUITEM
1M2 (3) DOOR326 200251
1
M2(3) DOOR UPPER INFILL
326 200242
2
M2 DOOR SLIDE
326 300043
2M2(3) DOOR STRIP SPACER326 20007
4
4HANK BUSH 304 SS M5600 80016
5
4M5 x 12 SS TRUSS HEAD SCREW600 800176
2
ANTI RATTLE BUTTON
18257
1
MAGNET
600 301828
2AL(3) DOOR BACK RAIL SUPPORT351 2007410
1M1(3) DOOR STOP BRACKET (LH)301 2000911
1
M1(3) DOOR STOP (RH)
301 2003512
2
SCREW 6g 12mm T304 SS SELF TAP
600 8005927
B
D
326 10007
9/02/2010
3-H
M2 (3) PASS-THROUGH DOOR ASSY
REV
1
2
10
DETAIL C
4
SPOT WELD TOP ONTO DOOR FIRST AND
APPLY A BEAD OF SILICON SEALER TO
THE INSIDE CORNER
3
INNER JOINS IN
CORNER FULLY
WELDED
2
7
5
6
8
4
10
4
3
5
5
12
6
6
7
8
11
12
7
7
27
27
