Washtech XP - Rack Slide Assembly

PERSPECTIVE VIEW
326 10011
16/09/2013
3-D
M2 \ XP RACKSLIDE ASSY
REV
Parts List
QTYDESCRIPTION
PART NUMBERITEM
1M2(3) RACK SLIDE SUB ASSY MK2326 100121
2M5 x 25 SS HEX HD SETsCREW600 800943
2
NUT NYLOC M5 S/S
600 800604
2
NUT SS 304 HEX M8
600 80023
5
1AL RACK SLIDE GUIDE351 200606
2M8x20mm Hex-Head Bolt600 80030
7
5
7
3
3
6
7
5
4
4
1
Service Manual XP-2
31
Revision 1C
