WaterLogic FIREWALL WL7 - User Interface and Dispensing Screen

8
ENG2036-15/01/19
Cold
8501
Bottles
Saved
COLD
Sparkling
2.2 USER INTERFACE  DISPLAY SCREEN
PRODUCT INFORMATION
Ambient
Rotate to select
· Bar with dynamic
glowing: chiller ON.
· Bar static: chiller OFF
Ice setpoint achieved.
· ON hot water option,
the white arrows indicate
the current temperature
of the water.
· Left: hot tank "cold".
· Right: current setpoint
(75,87°C or 93°C).
Press to dispense
Hot Extra-Hot
COLD
HOT
