WaterLogic WL2 Firewall - Mini Model Parts List - Continued; Mini Model Part Descriptions

38 39
Waterlogic 2 Firewall Technical Manual - Issue B, May 2014
N° Part Description
26 Sensor fixing Rubber
27 UV Sensor
28 15W UV Lamp
29 Firewall UV Lamp Fixing Rubber
30 Faucet UV - Spiral Quartz
31 Spiral Quartz Spacer to Outer Quartz Sleeve
32 Faucet Firewall Housing
Firewall Faucet Bracket
Firewall Housing Bottom Cover
Firewall Top Case
33 Wire from Ballast to UV lamp
34 JG 3/8" x 1/4" Reducing Fitting
35 Firewall Top Case Cover
36 Silver Front Panel for Drip Tray insert - Firewall
37 Firewall PCB Cover
38 Firewall Display PCB (Universal H&C,C&A,CO)
39 Silicon Button Key Mat CA
N° Part Description
40 Front upper insert panel
41 Button Label HC&CA
42 Drip Tray Grill
43 Drip Tray Body Charcoal with WL Logo
44 Firewall hot water faucet
45 Main PCB Fixing Bracket (FS)
46 Plastic PCB Support
47 JG Equal Elbow Connector 1/4"
48 Solenoid Valve DC24V 500mm
49 JG Equal Tee Connector 1/4"
50 15W Electronic Ballast
51 Power Transformer
52 Mini Upper Base
53 JG Equal Elbow Connector 1/4"
54 Cold Tank Assembly (4 Liters / No UV Holder)
55 JG Equal Elbow Connector 1/4"
56 Wire Condenser
