Waterlogic 2000IT Technical Manual - Issue B, December 2013
N° Part Description
28 PCB of WL2000 HC&CA
29 Silicon Button Key Mat WL2000 HC
30 WL2000 Front Hatch Panel Charcoal with UV Logo
31 Button Label WL2000 HC&CA
32 WL2000 Drip Tray Grill
33 WL2000 Drip Tray Body Charcoal
34 FS Silver Side Panel with handle hole
35 Drawn Hot Tank Ass'y 1.5L
36 WL2000 Upper Base
37 Power Transformer UV
38 Ballast metal cover
39 UV Lamp Fixing Rubber
40 UV Lamp Retaining Threaded Nut
41 UV Lamp 8W
42 O-ring
43 Quartz Sleeve D310mm for 8W Lamp
44 UV Cold Tank Assembly 4L
45 Wire Condenser
