B-1
B Specifications
This appendix includes specifications for the following:
•Physical
• Performance
• Analog input
• BCD input
• Power supply
• Communication interface
Physical specifications
Item Specification
Dimensions Height = 1.25 inches (3.18 cm)
Depth = 6.25 inches (15.9 cm)
Width = 5.25 inches (13.3 cm)
Weight 530 grams (15.1 ounces)
Power switch Front panel; pushbutton, On/Off
Power indicator Green LED (constant when power is on)
Status indicator Amber LED
Performance specifications
Item Specification
Analytical input range −0.25 to 2.25 Volts
Total input range (no damage) +/− 40.0 Volts (continuous)
Common mode voltage range +/− 3.0 Volts
Common mode rejection ratio
(60 Hz)
70 dB minimum
Input bandwidth 100 Hz
Power consumption 750 mW (typical)
