Watson-Marlow MC100 - Page 11

Users Manual
MC100
MC100 DeviceNet OM 1.01 EN.doc Version: 1.01 Page 11 of 36
X3 Communication Connector Connect with
1 RS485 – A I/O
2 TxD OUT
3 RxD IN
4 N.C.
5 GND -
6 NC
7 CTS OUT
8 RTS IN
9 RS485 – B I/O
9 pole SubD Male 9 pole SubD female
X4 Fieldbus Interface DeviceNet Connect with for example
1 OV Black V-
2 Data Blue CAN_L
3 Shield - SHIELD
4 Data White CAN_H
5 +24V Red V+
PHOENIX Part number
28 62 57 6
