Watson-Marlow MC100 - Detailed Description of the Adis

Users Manual
MC100
MC100 DeviceNet OM 1.01 EN.doc Version: 1.01 Page 22 of 36
7.2.3 Detailed description of the ADI’s
Default values are values in the MC100 after a factory default reset, the values depends on the pump
types and the examples below are for PD12B pump types
Instance 1 Volume
Attribute ID Description Type Value
1 Name Byte-String “Volume”
2 Data-type - double integer
3 Elements - 1
4 Access - Read/Write
5 Data value Double Integer Last Write value
6 Max. value Double Integer 9999,00000
7 Min. value Double Integer 0,01000
Read
8 Default value Double Integer 100,00000
Write 5 Data value Double Integer >= Min and <= max value
Instance 2 Tube
Attribute ID Description Type Value
1 Name Byte-String “Tube”
2 Data-type - Integer
3 Elements - 1
4 Access - Read/Write
5 Data value Integer Last Write value
6 Max. value Integer 10
7 Min. value Integer 1
Read
8 Default value Integer Dependant on pump
Write 5 Data value Integer >= Min and <= max value
Instance 3 Speed
Attribute ID Description Type Value
1 Name Byte-String “Speed”
2 Data-type - Integer
3 Elements - 1
4 Access - Get/Write
5 Data value Integer Last Write value
6 Max. value Integer 600 (tube dependant)
7 Min. value Integer 30
Read
8 Default value Integer 200
Write 5 Data value Integer >= Min and <= max value
