Watson-Marlow MC100 - Page 23

Users Manual
MC100
MC100 DeviceNet OM 1.01 EN.doc Version: 1.01 Page 23 of 36
Instance 4 Acceleration
Attribute ID Description Type Value
1 Name Byte-String “Acceleration”
2 Data-type - Integer
3 Elements - 1
4 Access - Read/Write
5 Data value Integer Last Write value
6 Max. value Integer 200 (tube dependant)
7 Min. value Integer 1
Read
8 Default value Integer 10
Write 5 Data value Integer >= Min and <= max value
Instance 5 Reverse
Attribute ID Description Type Value
1 Name Byte-String “Reverse”
2 Data-type - double integer
3 Elements - 1
4 Access - Read/Write
5 Data value Double Integer Last Write value
6 Max. value Double Integer 10
7 Min. value Double Integer 0
Read
8 Default value Double Integer 0
Write 5 Data value Double Integer >= Min and <= max value
Instance 6 Density
Attribute ID Description Type Value
1 Name Byte-String “ Density”
2 Data-type - double integer
3 Elements - 1
4 Access - Read/Write
5 Data value Double Integer Last Write value
6 Max. value Double Integer 2,00000
7 Min. value Double Integer 0,50000
Read
8 Default value Double Integer 1000000
Write 5 Data value Double Integer >= Min and <= max value
Instance 7 Calibration
Attribute ID Description Type Value
1 Name Byte-String “Calibration”
2 Data-type - double integer
3 Elements - 1
4 Access - Read/Write
5 Data value Double Integer Last Write value
6 Max. value Double Integer 2 * the value In instance 1
7 Min. value Double Integer 0,5 * the value In instance 1
Read
8 Default value Double Integer
Value from instance 1
(no calibration done)
Write 5 Data value Double Integer >= Min and <= max value
