OPTION 6 Instructions: Remote Setpoint, Direct Wired Header Temp Sensor, Modbus Setpoint
Drive
NOTES:
• Polarity must be observed for the RS485 connections. The ground for the shield is at
the “SHLD” terminal in the I/O the Board.
• The Outdoor Temp Sensor must be mounted on the North side of the building where
an average outside air temperature is expected. The sensor must be shielded from
direct sunlight as well as impingement by the elements. The Outdoor Temp Sensor
may be wired up to 200 feet (61m) from the boiler.
• There is no polarity to be observed. The ground for the shield is at the power supply
ground. The sensor end of the shield must be left free and ungrounded.
Step 3 – OPTION 6 CONFIGURATION
On All Boiler:
1. Go to: Main Menu → Advanced Setup → BST Cascade → Cascade Configuration:
• Set the Unit Mode parameter to BST Client.
2. Go to: Main Menu → Advanced Setup → BST Cascade → Cascade Communication:
• Set the Unit Address parameter to the communication address of the unit.
On the BST Manager only:
1. Go to Main Menu → Advanced Setup → BST Cascade, set the Parameters to the Values
in each menu in the table below.
Menu/Screen Name
Parameters
Values
Cascade
Configuration
Unit Mode
BST Manager
Hdr Temp Sensor
Header Temp
Application
Configuration
Application
Space Heating
SH Operating Mode
Rmt Setpt Netwrk
Cascade
Communication
Min Address
The minimum unit address in the cascade
Max Address
The maximum unit address in the cascade
Cascade Baud Rate
The baud rate for the cascade.
