Benchmark Platinum-Edge [II]: Operation-Service Manual
SECTION 6 – TROUBLESHOOTING
OMM-0137_E • GF-211 • 12/13/2019 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 151 of 153
Figure 10-1: SSOV Actuator with Gas Pressure Adjustment (SKP25)
BRASS HEX HEAD
(Remove to access
the Gas Pressure Adjustment
Screw).
DAMPING ORIFICE
COVER SCREW
