SECTION 4 – INITIAL START-UP
OMM-0137_D • GF-211 • 7/16/2019 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 45 of 146
PROPANE Combustion Calibration Instructions
NOTE:
These instructions assume that the inlet air temperature is between 50°F and 100°F
(10°C – 37.8°C). If NOx readings exceed the target values in Table 4-4, above, or Table 4-
6, below, increase the O
2
level up to 1% higher than the Target value. You must then record
the increased O
2
value on the Combustion Calibration sheet.
22. On Benchmark 3000 - 6000 units only, record the manifold (downstream) gas pressure at
100%. This value will be used in Section 5.2.2: Low Pressure Gas Test, and Section 5.3.2:
High Pressure Gas Test.
23. Once the O
2
level is within the specified range at 100%:
• Enter the Flame Strength, NOx and CO readings from the Combustion Analyzer
and multi-meter in the Manual Combustion Calibration screen’s Reading column.
• Enter the same values, plus the O
2
value, on the Combustion Calibration Data Sheet
provided with the unit.
24. Lower the Valve Position to the next calibration point using the  (Left) arrow key (if using
Method 1 in step 11) or the Fine Valve Position – (Minus) key (if using Method 2).
• BMK 750P & 1000P: 80%
• BMK 1500/2000/2500 DF & P: 70%
• BMK 3000 DF & P: 85%
• BMK 5000P & 6000P: 70%
• BMK 5000DF & 6000DF: 85%
25. Repeat step 17, 18 and 21 at that valve position and the rest of the valve positions in Table
Table 4-6a and 4-6b, depending on model. The O
2
, NOx and CO should stay within the
ranges shown in these tables.
TABLE 4-6a: PROPANE Final Valve Positions: BMK 750 – 3000
Valve Position Oxygen (O
2
) % Nitrogen oxide (NOx) Carbon Monoxide (CO)
BMK 750/1000
80%
5.5% ± 0.2%
<100 ppm
<150 ppm
60%
5.5% ± 0.2%
<100 ppm
<150 ppm
45%
5.5% ± 0.2%
<100 ppm
<150 ppm
30%
6.3% ± 0.2%
<100 ppm
<100 ppm
18%
5.5% ± 0.2%
<100 ppm
<100 ppm
BMK 1500
70%
5.2% ± 0.2%
<100 ppm
<150 ppm
50%
5.3% ± 0.2%
<100 ppm
<150 ppm
40%
6.2% ± 0.2%
<100 ppm
<150 ppm
30%
7.0% ± 0.2%
<100 ppm
<100 ppm
18%
8.5% ± 0.2%
<100 ppm
<100 ppm
