SmartPlate Installation, Operation & Maintenance Manual
APPENDIX E – PART LISTS
OMM-0069_0H • SP-100 • 1/30/2020 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 121 of 134
APPENDIX E – PART LISTS
SmartPlate SINGLE WALL – Base Components
Item #
Qty
Part #
Description
1
1
34026
BASE: SMARTPLATE
2
1
SEE TABLE
BRAZED PLATE HEAT EXCHANGER
3-A
1
SEE TABLE
PIPING ASSY, 1.5" 120V 60 Hz (See assembly drawings below)
3-B
PIPING ASSY, 1.5" 220V 50 Hz (See assembly drawings below)
3-C
PIPING ASSY, 1.5" 220V 60 Hz (See assembly drawings below)
4-A
1
SEE TABLE
PIPING ASSY, 2" 120V/60 Hz (See assembly drawings below)
4-B
PIPING ASSY, 2" 220V/50 Hz (See assembly drawings below)
4-C
PIPING ASSY, 2" 220V/60 Hz (See assembly drawings below)
5
1
24198
SUPPORT BRACKET ASSEMBLY, BRAZED HEAT EXCHANGER
6
1
35015
SUPPORT A-FRAME, SMARTPLATE
7
1
33084-1
BRACKET UPPER PIPES
8
2
33084-2
ADJUSTER PIPE SUPPORT
9
1
33083
BRACKET, MIXING BOX
10
2
33085
BRACKET LOWER PIPES SUPPORT
20
1
33086
SUPPORT CONTROL BOX
22
1
73072
PLATE, RATING
31
1
69096
CONTROL BOX ASSY, SMARTPLATE
Description
Item 2
Item 3-A
Item 3-B
Item 3-C
Item 4-A
Item 4-B
Item 4-C
SP-23
120V 60 Hz
28121-1
22263-1
220V 50 Hz
22263-3
220V 60 Hz
22263-5
SP-33
120V 60 Hz
28121-2
22263-1
220V 50 Hz
22263-3
220V 60 Hz
22263-5
SP-45
120V 60 Hz
28121-3
22264-1
220V 50 Hz
22264-3
220V 60 Hz
22264-5
SP-69
120V 60 Hz
28121-4
22264-1
220V 50 Hz
22264-3
220V 60 Hz
22264-5
SP-150
120V 60 Hz
28121-5
22264-1
220V 50 Hz
22264-3
220V 60 Hz
22264-5
AERCO
International, Inc.
Blauvelt, NY 10913
SmartPlate Single Wall Part List
02/27/2017
29381-TAB rev F
Sheet 1 of 2
