SmartPlate Installation, Operation & Maintenance Manual
CHAPTER 8 – CORRECTIVE MAINTENANCE
OMM-0069_0H • SP-100 • 1/30/2020 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 62 of 134
SINGLE-WALL HEAT EXCHANGER REPLACEMENT Instructions
SUPPORT
FRAME
HAND HOLE
CUTOUT
(BOTH SIDES)
HEAT
EXCHANGER
(HX)
MOUNTING
ATTACHMENT
4 PLACES
(VIEW “A - A”)
A
A
SUPPORT
FRAME
HEAT EXCHANGER
MOUNTING TAB
(4 PLACES)
FLAT
WASHER
HEX HEAD
BOLT
HEAT
EXCHANGER
REAR VIEW
VIEW “A - A”
HEX
NUT
Figure 8-4. Heat Exchanger Mounting Details
