RS485 TO ETH ( B)
4 . 2 . HARDWARE CONNECTION
Generally speaking, the serial server only needs to be connected to the power supply, serial
port, and network cable.
The network port is connected to a common network cable, which can be directly connected
to a computer or connected to the network through a switch.
4 . 3 . SOFTWARE INSTALLATION
Vircom can be used to configure parameters such as device IP and create virtual serial ports.
If you do not need the virtual serial port function, you can only download the
installation- free version of the configuration software.
Table 3 Software description
Chinese version configuration software
English version configuration software
Virtual serial port software
4 . 4 . PARAMETER CONFIGURATION
After Vircom is installed and the device hardware is connected, run the software as shown
in the figure, and then click "Device Management" as shown in the figure. Using Vircom, you can
11 / 52 www.waveshare.com
