PICO PARTS OVERVIEW
Meet your Pico
™
ADVENTURES AWAI T
INSTR U C TI ON MANUAL
Forward-Facing Car Seat
For kids 22 to 50 lbs. (10 to 22.7 kg) / 30 to 45 in. (76 to 114 cm)
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
Backrest
Shoulder Strap Pads
Chest Clip
Shoulder Straps
Buckle Tongues
Buckle
Hip Straps
Buckle Strap
Headrest
Lap Belt Guide
Seat Bottom
Buckle Pad
Fold Release
Headrest Adjustment Button
Tether Strap
Tether Hook
Tether Storage Pocket
Instruction Manual Storage Pocket
Lower Anchor Belt (LATCH)
Push-On Connector (LATCH)
Lower Anchor Belt Adjuster (LATCH)
Push-On Connector Storage Bar
Car Seat Frame
