Orifice kits for the HSG200 and HSG400 burners are available from Wayne Combustion Systems.
Some HSG burner models are sold to Original Equipment Manufacturers
and are pre-set with the proper orifice for the firing rate and gas utilization for the specific
equipment. Before attempting to convert this equipment from one gas to another, consult the
equipment manual or contact the equipment manufacturer for the procedure on gas conversion.
SECTION IV: CONSUMER INSTRUCTIONS
GENERAL INSTRUCTIONS FOR SERVICING BURNER
A homeowner should be able to check several possible causes of shutdown before calling in a
serviceman. The following check list may eliminate the need for a service call or at least provide
information for the serviceman.
1. Check thermostat. Make sure that it is set at the desired room temperature. If the thermostat is
damaged or loose on the wall, have it replaced or repaired.
2. Check fuses in service box for the burner circuit. Replaceable type fuses should not be loose in
the socket. If a fuse is blown out or if in doubt, replace with the same size and type. If circuit
breaker is in the service box, check position of indicator. If tripped, reset.
3. Check on-off switch for the burner circuit, it may have been accidentally turned off.
It is advisable, periodically, to visually inspect the burner. Check air inlet blower to make sure it
is not clogged or blocked. Check air shutter to make sure that it has not been tampered with,
make sure that it is in the same position as when final adjustments were made. Check blower
wheel to see if it is dirty or full of lint. The areas around the conversion burner should be kept clear
and free of combustible materials, gasoline and other flammable vapors and liquids. The flow of
combustion and ventilating air to the burner must not be blocked or obstructed in any manner.
CLEANING OF BURNERS (BY SERVICEMAN ONLY): Remove the burner from the appliance and
visually inspect the blast tube for any deterioration. Check burner head, electrodes, etc. with
illustrations in the owner’s manual for proper locations.
PROFESSIONAL SERVICE REQUIRED
Gas burners require the services of an experienced technician
for proper setting and adjustment. If the burner does not appear
to be operating properly, DO NOT ATTEMPT TO ADJUST THE
BURNER YOURSELF, but call in a competent serviceman.
