920943 Rev E July 2014 1
1 INTRODUCTION
1.1 Dispenser Covered
This manual describes the installation and operation of the Wayne Reliance
®
S1 G6101D Mechanical
Registration AST (above-ground storage tank) Fleet Remote Dispenser. This dispenser displays volume
only. This series includes the following base model:
Model
Number
Type Hoses Products Solenoid
Valves
G6101D/ Single 1 1 1” (2.5 cm)
The G6101D includes the following options as standard: enhanced capacity - 1” piping [2 suffix], AC
junction box [J suffix], and hose hanger [K suffix]. Other optional equipment, also represented by model
number suffix designations, is shown in Section 1.2.
Any questions concerning the installation and operation of the dispensers that are not covered in this
manual should be referred to your local Wayne authorized service personnel or call the Wayne Help Desk
at 1-800-289-2963 or e-mail support@wayne.com.
NOTE: Terminology Used in This Manual:
Dispenser(s):Generic term used to refer to any model in the Wayne Reliance Series.
Remote Dispenser(s): Models utilizing a submersible pump in the tank to
provide fuel to the dispenser.
