Wayne WLS Series User Manual

5
www.waynepumps.com
WLS Series
WIRE AND FUSE SIZES
For recommended Wire and Fuse Sizes, refer to your local building codes for recommendations and compliance.
Pipe Size
(inches)
PSI Friction Loss in 100 Feet of Pipe
US Gallons per Hour
1200 1500 1800 2400 3000 3600 4800 6000 7200
1.25
2.6 3.9 5.5 9.4 14.1 22.0
1.5
1.2 1.9 2.6 4.4 6.7 9.4 17.5
2.0
0.6 0.8 1.3 2.0 2.8 4.7 7.1 10.0
2.5
0.6 0.8 1.2 2.0 3.1 4.3
