INSTRUMENT AND CONTROL FUNCTIONS
Horn switch
Press this
switch to sound the horn.
Right turn signal indicator lamp
-
shes whenever the turn signal switch is
pushed to the right side.
Speedometer and odometer
The dashboard unit is equipped with
a speedometer and an odometer. The
speedometer shows the riding speed.
The odometer shows the total distance
traveled.
Voltage meter
The voltage meter indicates voltage le-
vel of the battery.
HANDLEBAR SWITCHES - LEFT
1. High/Low beam switch /
2. Turn signal switch
3. Horn switch
High/Low beam switch /
Set this switch tof for the high
beam and to
for the low beam.
Turn signal switch
To signal a right-hand turn, push this
switch to
. To signal a left-hand turn,
push this switch to .
