PERIODIC MAINTENANCE AND MINOR REPAIR
!
WARNING
-
ned as described, have a dealer make
BRAKE PADS / BRAKE SHOES
The front brake pads and the rear bra-
ke shoes must be checked for wear at
maintenance and lubrication chart.
1. Wear indicator
2. Brake disc
3. Brake pad
position of the wear indicators while
applying the brake. If a brake pad has
worn to the point that a wear indicator
almost touches the brake disc, have a
dealer replace the brake pads as a set.
Front brake pads
Each front brake pad is provided with
wear indicators, which allows you to
check the brake pad wear without
having to disassemble the brake. To
check the brake pad wear, check the
Rear brake shoes
lever before riding. To check the bra-
-
le nut if the nut position reach to the
end, have a dealer to replace the brake
shoes as a set.
BRAKE FLUID
!
WARNING
enter the brake system, possibly
causing it to become ineffective. Befo-
