Operation Guide
Issue V1.0 (2019-05-08)
1
1 OSD Main Menu
1.1 Procedure
1.1.1 Camera Control Using Five Buttons
If your camera has four arrow buttons and one SET button, you can use the buttons to operate the OSD
main menu. Figure 1-1 shows the five buttons.
Figure 1-1 Five-button layout
The buttons have the following functions:
SET: Press this button to open the OSD main menu or end setup.
UP/DOWN: Press the two buttons to select the upper or lower menu.
LEFT/RIGHT: Press the two buttons to select different modes.
----End
1.2 OSD Main Menu Interface
The OSD main menu interface includes AE, AWB, DAY-NIGHT, VIDEO OUTPUT, LANGUAGE,
RESET, SAVE - EXIT, and EXIT, as shown in Figure 1-2.
