SECTION 9: UPRIGHT INSTALLATION
17
Step 1: Assemble using the provided hardware: 3/8" bolts, nuts and lock washers. Assemble the legs with
the top upside down on a flat surface. See Page 17, Figure 5.
FIGURE 5: Step 1
Step 2: Attach the mounting feet to each leg using supplied hardware. See Page 17, Figure 6.
FIGURE 6: Step 2
