WebastoAirTopInstallationGuide–AT2000STC
10
AirTop2000STCInstallationGuide2020|WebastoThermo&ComfortAustraliaPtyLtd.
3.1 FuelpumpWiring
A7mfuelpumpharness(Fig14)issuppliedinthekittoconnecttothefuelpump.Blueandbrown,twincore
harnessconnectstothetwoblackwiresoutofthecombustionairinlet(Fig3)(3).PolaritydoesNOTmatter.
Plugkitsaresupplied;spadeterminalsorstandardautomotiveelectricalconnectionscanbeused.
Note:Neverrunthewiresthroughthecombustionairinlettube,asitwillcreateairrestrictions.Ref:Section
2–(2.4&2.5)
 
3.2 InstallationofControlElement
 
Installthecontrolelementinaconvenientlocation.Thecontrolelementdoe snotmeasuretemperature.The
monitoringoftemperatureisregisteredviaareturnairtemperaturesensorlocatedinsidetheheater.


Fig14–Fuelpumpwiringharness
Fig17–RotaryController‐connectsto
plug(Fig10)(X9)
Fig16–MultiController–
completewithmountingkit
Fig15
–
Wiringtothefuelpump
