4FuelSystems
















Forcaravans,Webastocansupplya12Lplasticfueltankwithsightlevelgaugeandaquickconnectforthefuelline.
WithMotorhomes,fuelcanbesourcedoutofthevehicle’sownfueltankviaafuelpickupsuppliedwiththekit.
Note:
Whensourcingfuelfromvehicle’sfueltank,donotcutintothereturnorsupplylinefortworeasons:
1. Latestmodelvehicleshavehighlypressurizedfuelsystems.
2. Ifyouperformanymodificationstothevehicle,youmayvoidthevehiclewarranty.
Ensurethattheclampsaretight
onthefuelfilterandthefuelpumpandfollowthedirectionoftheflowasshownby
arrowsonthefuelfilterandthefuelpumpforcorrectoperation.Thefuellinescanbeprotectedinconduitandcable
tiestosecure;thesearenotsuppliedinthekit.

4.1Installation–FuelPump

Ensurethatthefuelpumpisinstalledwiththeclamp,90degreeelbowandtherubbermountingbracketsuppliedin
thekit.Thiswillreduceresonationthroughthevehicle.(Fig20)




Fig19
–
SamplefuelsystemlayoutwithWebasto12Ltplasticfuelandvehiclefueltank.
Fig20Fuelpumpinstalled
withrubbermounting
bracket(below)
