WebastoAirTopInstallationGuide–AT2000STC

3
AirTop2000STCInstallationGuide2020|WebastoThermo&ComfortAustraliaPtyLtd.


Pre‐InstallationConsiderations
1) Locationandorientationoftheheater.
Theheatermaybefittedtotheinteriororexteriorofthevehicle.Ifitisinstalledexternally,ensurethattheheaterisfittedin
apositionwhereitisprotectedfromwateranddustingress.
2) Lengthofhotairoutletducting–theshorter,thebetter.Ensurethatthehotairoutletisnotdirectedtowardsor
incontactwiththehumanbody,asthehotairtemperaturecanrangefrom80‐120
o
C.
3) Returnvent‐insomecaseswherethereisenoughaircirculationinandaroundtheheater,ductingmaynotbe
requiredtothereturnairvent.Whereitisrequired,keepductingtoaminimum.
4) Locationofthecontroller,electricalwiring,fuseandbatteryconnections.
5) Locationof
thefuelpumpandfuelfilter.
6) Locationoftheexhaustsystem.Ensurethattheexhaustisnotfacingdirectionoftravel.
7) Locationofthecombustionairsystems.
8) Fuelpick‐upoptions–12LWebastofueltankorstandpipe.
9) Electrical‐ensureto usethesuppliedfusesin
thekitandbatterypositiveandnegativeconnec teddirectlytothe
housebattery.

Tips
Looselyattachtheheaterwiththemountingbracketandplaceitinyourdesiredlocationtopredeterminetheheater
orientation,ductinglayout,airflow,wiring,controllerandgeneralclearanceforeasyaccessibilityandforfuture
serviceandrepair.
SerialNumberLabelling
Ensurethattheserialnumberlabelsareattachedonthetoporthesideoftheheaterincasetheheaterismounted
againstawallandtheoriginallabelmaybeinaccessible.Additionallabelsaresuppliedinthekitandoneshouldgo
ontheinstallationmanualenvelopetohand
overtothecustomeratthetimeofcommissioning.
    

TheSerialNumberlabelontheAT2000STCwillstillstateAT2000ST.Thisistoavoidthenecessityofapplyingfora
newECtypeapproval.TheheaterwillstillbeanAT2000STCbasedonthemanufacturedateandserialnumber.

Note:Incaseofwarrantysituations,theserialnumber
willberequestedbyWebastooranauthoriseddealerto
validate.
Fig1–Serialnumberlabels–Heater
Fig2
–
SerialnumberlabelwrittenasFabrNr.
