Webasto AT2000STC User Manual

WebastoAirTopInstallationGuide–AT2000STC

21
AirTop2000STCInstallationGuide2020|WebastoThermo&ComfortAustraliaPtyLtd.

11PreventiveMaintenance

Toensuretrouble‐freeoperationofyourWebastoheater, pleaseobservethefollowing:
1) Operateheaterforatleastanhouronceamonth,regardlessoftheseason
2) Keepreturnairinletandhotairoutletfreeofobstructionstopreventoverheating
3) Keepcombustionairinletandexhaustoutlet
tubefreeofdirtandobstructions
4) Changefuelfilterannually(dependingontheusage)
5) BioDieseloranyfueladditiveisnotpermitted
6) 15Afuseforboth12Vand24Vheaters

Note:Thebuild‐upofCarbonisnotawarrantablecondition. 
SituationsthatmaycauseCarbon
build‐upintheheaterare:
 UnderVoltage:thesystemshouldhaveatleast12.5‐13V;
 Lowcurrent:thesystemrequires7‐8Afortheinitialstart‐upphasefor120secondsandoncetheflameis
establishedtheglowpluggoesoutandheatercontinuesrunningat2‐3A;
 Undersizewire:whereextensionsaremadetothebatterypositive&negativecablesonl y ,ensurethatcorrect
wiresizeisused;
 Fuelsystem:poorfuelqua lity,airpocketsinthefuellineorrunningoutoffuel;
 Combustionsystem:anyblockageorrestrictioninthecombustionairtubeoratthesilencer;
 Exhaustsystem:anyblockageorrestrictionintheexhaustmufflerorpipe;
 Isolationswitchorcircuitbreaker:canpreventtheheaterfromperformingacorrectshutdowncyc le.The
batterypositive&negativewireshouldbeconnecteddirectlytothebattery;
 Electricalconnections:poorbatteryconnections,poorEarth,loosefusesandimpropercrimpingofterminals
orplugs.
Thebuild‐upofCarbonisnotaproductmalfunctionhowever;theabovelistedareexternalfactorsthatcould
affecttheperformanceoftheheater.

12FaultCode
Intheeventofafailure,aflashcodewillbegeneratedontheindicatorlightoftheRotaryControl(On/Off)switch.In
ordertomakeacorrectanalysis,itisnecessarytounderstandthefaultcode.Theflashingcodewillbevisibleduring
thecooldownperiodoftheoperation.

Duringtheflashcodeeventyouwillseefivequickflashesfollowedbyasequenceofslowflashes,thesequenceof
slowflashesistheactualfaultcode.Thefivequickflashesareonlyanindicationthatafaulthasoccurred.
Countonlytheslowsequenceoftheflashesto
obtainthecurrentfaultcode.




E.g.CodeF03=loworhighbatteryvoltage
Pause
Pause
F03 =
Quick flashes x5
Quick flashes x5
Number of slow flashes

Webasto AT2000STC Specifications

General

Brand	Webasto
Model	AT2000STC
Category	Heater
Language	English
