WebastoAirTopInstallationGuide–AT2000STC

12
AirTop2000STCInstallationGuide2020|WebastoThermo&ComfortAustraliaPtyLtd.

4.2InstallationofFuelStandPipe

Whenfuelissourcedoutofthevehicle’sfueltank,ensurethatthestandpipeisinstalledonaflatsurfaceandcut
thestandpipelengthsothatitis25mmfromthebottomofthetank.SeeFig21/22.

  

InstallthetankextractingdeviceasshownFig21
Shortentheimmersiontube;theendshouldbeapprox.25mmoffthebottomofthetank.Cutthetubediagonally
andensureyoudeburrthecutedges.(Fig21)
Drilla25mmholeontheflatsurfaceofthetank(Fig
22).Ensureyougreasethedrillbitanddrillingsurfaceorapply
maskingtapebeforehand(tocatchsmalldrillingchipsorswarfenteringthefueltank).
Installthefuelpickupandtightenthelockingnut(thesealshouldbeslightlycompressed;applyinganylockingglue
willbeadvisable).

4.3FuelFilter
Toensureacleancombustionprocess,afuelfilterissupplied.Alwayscheckthedirectionofflowasmarkedonthe
filter(Fig23).Thefiltershouldbeinstalledbetweenthefuelsourceandthefuelpump.








DonotsubstitutetheWebastosuppliedfuelfilterwithnonWebastoreplacement.


Fig21–Installingfuelextractingdevice–(TopMounttype)
Fig22–25mm‐FuelExtractingDevice
Fig23–WebastoGenuinefuelfilter
