BlueCool S Series 5 Installation
13
5.7 Installing sea water circuit
NOTE
The sea water components must be installed
with a continuous uphill slope from the through-
hull fitting to the strainer and pump to the air-
conditioning unit.
This ensures that no air bubbles collect in the sea
water circuit which can lead to a malfunction of
the pump.
Fig. 8 Sea water circuit
1 = Through-hull fitting with sea valve
2 = Sea water strainer
3 = Sea water pump
4 = Bleeding valve
5 = Air-conditioning unit
6 = Sea water outlet
1
2
3
5
4
6
