BlueCool S Series 5 Installation
17
Screw out the screws of the fan motor and carefully remo-
ve the fan without bending the impeller. The power cable
to the fan can remain connected when doing so.
The fastening screws of the fan housing are now acces-
sible through the opening of the fan motor. Screw out the
screws, remove the fan housing and remount it in the de-
sired position.
Remount the fan motor.
Transition boxes
The transition boxes behind the supply air grilles are used as
a compensation volume for the air flow and therefore
reduce the noise level of the air flowing through the grille.
Therefore, the depth of the transition box has a major effect
on the distribution of the air flow.
Install the return air grille.
Install the transition box and the supply air grille.
Install the insulated air ducts from the air-conditioning
unit to the transition box.
Fix the air ducts in place so that they do not move even at
higher fan speeds.
