6
VW Passat
Electrical - Overview
ATTENTION
The routing of cables and wires are done in accordance to the general valid rules of engineering. If not described
differently, securing of wiring and cables is done with cable ties to the vehicle’s own wires and cable harnesses.
ATTENTION
Timer control location is a recommendation only. Please consult with the customer before mounting.
Fuse Block/Relays/Resistor HVAC Blower Motor
(1) Fuse Holder (1) Blower Control Integration
(2) Relays (2) Glove Box Area
Digital Timer (Sample Location) Fuel Metering Pump
(1) Webasto Digital Timer (1) Fuel Metering Pump
(2) Right Rear Side of Vehicle
1
2
1
2
1
1
2
To Next Page
