Webasto DBW 2016 Installation Instructions

To install the circulating pump DBW 2010 / 2016
36
5 To install the circulating pump
The circulating pump is installed as shown in Figure 7 (U 4810) and 9
(U 4840). Note the installation position.
NOTE:
The pump ports and connection lines from the water intake and water
outlet must be flush (no stress).
5.1. U 4810 circulating pump
Fig. 6: Delivery rate and flow resistance
U 4810 circulating pump
Delivery rate
(with water at 20 °C)
Flow resistance
(with the pump stopped)
Fig. 7: U 4810 circulating pump installation position
1303560C_DBW 2010 EA_degbfr.book Page 36 Tuesday, March 5, 2013 9:05 AM
