DBW 2010 / 2016
Installation example for DBW 2010 / 2016
35
4
Inst
allation example for DBW 2010 / 2016
Fig. 5:
Installation example for DBW 2010 / 2016 heaters
1
Wall heater with fan
2
Heat exchanger at entry poin
t
3
Heater
4
Circulating pump
5
Roof heat exchanger
6
V
ehicle engine
7
Driver
’s position heating system
8
Control element
Forwards
Backwards
W
ater heating circuit – wall heater and ro
of duct heating system
1303560C_DBW 2010 EA
_degbfr.book Page 35 Tuesday, March 5
, 2013 9:05 AM
8
10
Table of Contents
Table of Contents
2
Statutory Regulations Governing Installation
3
Use / Version
5
Installation
6
Installation Example for DBW 2010 / 2016
9
To Install the Circulating Pump
10
Connection to the Vehicle Cooling System
12
Fuel Supply
13
Combustion Air Supply
15
Exhaust Pipe
16
Electrical Connections
18
Initial Start-Up
25
Troubleshooting
26
Technical Data
27
Technical Data
28
